X-Bar category

X-Bar to suit Ram 1500 DT Cab Chassis (10/2020 on)

03467XW

A rugged, go-anywhere towbar engineered for off-road. The X-Bar provides an increased departure angle and 3 rated recovery points to get you out of any situation. While practical design elements such as integrated bash plates and protected trailer plug mounting points keep you going when the going gets tough. This X-Bar recovery towbar (Part Number:03467XW) is designed to fit perfectly with your Ram 1500 DT Cab Chassis and tested to meet Australian ADR standards. With Hayman Reese Towbars you can be assured that you’re getting the maximum towing capabilities and safety on your travels.

  • Share
Item number: 03467XW
Categories:

Australia Wide Installers

NATA Accredited Testing Laboratory

Overview Specifications

A Rated Recovery Towbar

The Ram 1500 DT Cab Chassis X-Bar has a towing capacity of 4500kg with a ball weight of 450kg. The X-Bar comes with a rated 8 tonne centre recovery point and two rated 4 tonne side recovery points. Whenever you are recovering a vehicle that's stuck always make sure you use a rated recovery point as using other methods may cause damage or injury. The X-Bar also has a number of features beneficial to offroad travelling including quick release cover protecting plug points, designed to suit your vehicle, Twin protected trailer socket mount points, SmartPin™ hitch pin, premium eCoat & powder-coat finish and rated D-shackles.

Superior Construction

The X-Bar is designed to maximise towing ability and allow you to safely recover your or a mates vehicle. The 03467XW X-Bar Recovery Towbar includes increased thickness sidearm and custom forged 700-grade steel recovery points and towball mount. The X-Bar has been designed using advanced FEA (Finite Element Analysis) technology and tested to Australian Standards AS/4177 and ADR 62/02 in a dedicated NATA accredited Laboratory at Hayman Reese’s Melbourne Production Facility for both towing strength and recovery ability.

Towbar Rating 4500kg
Ball Weight 450kg
Bumper Cut No
Product Weight 62.5kg
Product Dimensions 113 x 33 x 29cm
SmartCODE Compatible No
Installation Required Yes
Finish Powder coated
Notes 4500/450kg rating with 70mm ball. 3500/350kg rating with 50mm ball.
Tail Length 400mm
Colour black
Hitch Type 50mm square hitch receiver
Exposed/Concealed Fitment Concealed
LUG 21366
Fitting Difficulty Specialist Installer
