Towbar to suit Land Rover Discovery (12/2016 on)
With a tow capacity of 3500kg and a ball weight of 350kg this towbar is specifically designed for towing caravans, large trailers, boats or horse floats. This towbar has a concealed design and doesn't require a bumper cut. The Towbar has a removable Tow ball mount (TBM) with 50mm tow ball, rated D-shackles and Smart Pin all included.
- Share
Australia Wide Installers
NATA Accredited Testing Laboratory
Made for Land Rover Discovery (12/2016 on)
A Hayman Reese towbar is a high-quality upgrade to your vehicle that allows you to tow caravans, trailers, boats and more with maximum safety. This Towbar (Part Number:03224R) is designed to fit perfectly with your Land Rover Discovery (12/2016 on) and tested to meet Australian ADR standards. With Hayman Reese Towbars you can be assured that you’re getting the maximum towing capabilities and safety on your travels.
What can it tow?
The Land Rover Discovery (12/2016 on) heavy duty (Class 4) towbar has a towing capacity of 3500kg with a ball weight of 350kg this towbar is specifically designed for towing caravans, large trailers, boats or horse floats. Ensure that when carrying bike racks and other items with vertical force on the towbar that you check the owners handbook for weight limits.
How will my towbar look
This towbar has a black powdercoat finish and a concealed design which hides the majority of the bar from view, with only a hitch receiver visible. The hitch receiver is a standard 50mm square receiver, with chrome hitch collar and comes standard with a removable Tow Ball Mount (TBM), 50mm tow ball and rated D-shackles. When you’re not towing, simply remove the retaining clip and hitch pin and the Trailer Ball Mount slides straight out.
Safe Towing
Hayman Reese towbars are designed to be compatible with Weight Distribution systems, used to safely tow Caravans and large loads, along with hitch mounted accessories such as bike racks and platforms. They come standard with a tow ball but also work with a DO35 Pin and off-road coupling.
Superior Construction
Hayman Reese towbars are designed to maximise towing ability. The 03224R Heavy Duty (Class 4) Towbar has been designed using advanced FEA (Finite Element Analysis) technology and tested in a dedicated NATA accredited Laboratory at Hayman Reese’s Melbourne Production Facility. This gives us the confidence to provide a lifetime warranty on the towbar for you as the original owner.
Whether you’re taking a caravan around Australia, going on a camping trip, a fishing adventure, a family holiday or need to tow for work, we'll keep you connected and help you get there safely.
Towbar Rating | 3500kg |
Ball Weight | 350kg |
Bumper Cut | No |
Product Weight | 5.53kg |
Product Dimensions | 25.5 x 20.5 x 13cm |
SmartCODE Compatible | No |
Installation Required | Yes |
Finish | Powder coated |
Notes | Landrover Discovery 5 comes with OEM fitted towbar structure and wiring but no ball mount. This kit provides towball mount towball shackles pin and correct compliance labels. Vehicle is prewired. |
Colour | black |
Hitch Type | 50mm square hitch receiver |
Exposed/Concealed Fitment | Concealed |
LUG | GT507 |
Fitting Difficulty | Specialist Installer |
ECU | Not applicable |
